Key Features

Feature	Benefit	Result
Wi-Fi 6 for high performance and efficiency	Boost speed and efficiency for all devices	Up to 4x faster speeds and improved efficiency compared to Wi-Fi 5, reducing buffering and lag.
Supports up to 75 associated clients per radio	Connect more devices without slowdowns	Handle up to 75 devices per access point, ideal for high-density environments like classrooms or offices.
Support for WPA2/WPA3 protected employee and guest login with Enhanced Open for per user guest access	Secure Wi-Fi for employees and guests	Enhance data security with WPA3 encryption, reducing the risk of data breaches.
Incredible Efficiency with Wi-Fi 6	Simplify deployment and management	Deploy and configure access points in minutes with easy-to-use web interface and automatic configuration, saving IT time and resources.
Reduce High Cost of Cabling with Full-scale Wireless Mesh Coverage	Extend Wi-Fi coverage to hard-to-reach areas without extra cables	Eliminates the need for additional cabling, potentially saving thousands of dollars on installation costs.
Safeguard Sensitive Data with WPA2/WPA3 and Enhanced Open	Protect your network and data with robust security features	Provides integrated firewall and intrusion detection to prevent unauthorized access and protect sensitive data.
Creates a Custom Guest Access Experience	Offer a branded and customizable guest Wi-Fi experience with social media login and captive portal options	Increase brand awareness and collect valuable customer insights through branded guest Wi-Fi pages and captive portal integrations.

Specifications

CertificationsEN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Input voltagePower over Ethernet (POE): 802.3af (class 3)
DC power (12V)
Note: Power sources are sold separately

Wi-Fi antennaIntegrated down-tilt omni-directional antennas for 2×2 MIMO with peak antenna gain of 4.3dBi in 2.4GHz and 5.6dBi in 5GHz (of the effective, combined pattern for both antennas in each band).

Connectivity, standardIEEE 802.11ax

Ports(1) uplink Gigabit Ethernet port, with POE-in support (802.3af)

MountingThe access point ships with a white mount clip that can attach to both wall and ceiling.
You can also purchase a mount (R6P90A) that matches the aesthetic design and looks of the APs, to blend seamlessly into your environment.

Power consumptionMax power consumption (worst-case): 10.1W (PoE), 8.8W (DC)

Radio coverageDual Radio for simultaneous dual-band operation
5 GHz 802.11ax 2×2 MIMO for up to 1.2 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2×2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)

WarrantyAruba Instant On 2 Year warranty with 24X7 phone support for first 90 days and chat support for the entire warranty period. Community support as long as you own the products.

Weight500 g (1.1 lb)

Dimensions37x 160 x 160 mm (1.5 x 6.3 x 6.3 in)
